THERMOSLATE generates renewable solar energy while untouching the beauty of the roof and natural slate.

Hook System

The THERMOSLATE hook installation provides a perfect integration to roofs using 3.5mm thick slates and traditional fixings.

The result? A natural slate roof which has less environmental impact and an innovative invisible solar system.

Previous
Next

Ask for a simple now. Leave your contact details and we will send you a free sample so you can get to know our product.

Characteristics

THERMOSLATE is compatible with any accumulator and pump brand and model on the market. Likewise, it is also compatible with radiant flooring systems or low-temperature convectors (radiators of 45°C – 60°C)

The THERMOSLATE® hook fixing system allows completely undetectable integration of the thermal solar collectors into any traditional natural slate roof. The stainless steel hooks facilitate perfect fitting of each of the slates. This means that, as well as taking advantage of the sustainability of renewable energies, THERMOSLATE® enhances the natural beauty of slate roofs.

thermoslate solar slate with hook detail
Sistema Pizarra Thermoslate

Quantity of fluid/m2

0,38L

Weight/m2 (empty)

21 Kg

Dimensions

Slate dimensions:
32x22cm, 35x22cm, 40x22cm
Nominal collector thickness: 35mm

Fijaciones Pizarra

Fixings

Visible
Hook

Dimensions

The THERMOSLATE® system with hooks is compatible with the most widely used natural slate formats, 22 cm wide and 32 cm length, ensuring perfect adaptation of the solar thermal collector to any roof.

THERMOSLATE® solar collectors are completely imperceptible once properly installed.

CHARACTERISTICS THS.4022.S11
SLATE FORMAT (cm) 40x22
OVERLAP (cm) 11
EXTERNAL DIMENSIONS 2458x745x37
TOTAL AREA (m²) 1,83
TOTAL CATCHMENT AREA 1,41

Please visit our resource centre for product details, technical information, fixing guides and certifications.
