CUPA PIZARRAS has been producing the most complete range of natural slate for roofing and facade since 1892.

CUPA 18

icono-case3

Colour

Grey
icono-case3

Surface

Smooth

Non-carbonated slate formed by tectonic compression. Dark grey slate with thin laminations and a smooth surface.

Note: As this is a natural product it is possible that there will be a shade variation.

Previous slide
Next slide

Origin

Quarry La Campa.
Folgoso del Caurel (Lugo) Spain.

Operations start date

Operating since 1972

Dimensions

Sizes: Between 20x20cm and 60x45cm
Thickness: 3.5 – 5 – 6 mm

Selections

R EXCELLENCE, H, NATURAL

Formats

Rectangular is the most common model in the UK Market. If you are interested in other formats or sizes, please contact us.
square model
Square
Rectangular
Half moon
Schuppen
Spitzort
Fischschuppen
90Âş Sawn

International Certifications

CUPA 18 roofing slates meet the following international standards

marcado ce
EN 12326
cupacladcert7
ATG/H962
bsi-certificate
BS EN 12326:2014

Technical specifications

Technical documentation (declaration of performance, certifications, …) available in the resource center.

Water absorption
0,16% Code : W1 (< 0,4%)

Contents of carbonate non carbonated
0,55% Fulfill (< 1,5%)

Mor characteristic
Longitudinal 59,8 MPA

SO2 exposure test
S1

Thermal cycle test
T1

Freeze thaw test
Fulfill < 0,6%

Would you like to see a sample? Please complete the form to receive your slate sample.
